Switch Difference: 4% RH (±3% tolerance)
Permissible Air Velocity: 15m/sec
Contact Type: Change-over contact
Contact Resistance: <10m Ω
Service Life: >100,000 cycles
Min. Switching Capacity: 20V AC/DC, 100mA
Max. Switching Capacity: 250 VAC, 5 (1) A DC 20W
EMC: Acc. to EN 55014-1-2, EN61000-3-2, EN 31000-3-3
Connection: 3-pole terminal clamping torque 0.5 Nm max stranded wire (with wire end ferrule) 1.5mm2
Mounting: 35mm DIN clip for 35mm DIN rail, EN60715 or for exit filter EF 118 Series
Casing: UL94, Plastic according to UL94, V-0, light grey
Dimensions: 67x50x38mm
Weight: Approx. 60g
Fitting Position: Variable
Operating/Storage Temperature: 0 to + 60 °C (+32 to + 140 °F) / -20 to +80 °C (-4 to + 176 °F)
Protection Type: IP20
