Switch Temperature Difference: Approx. 3K
Sensor Element: PTC
Contact Type: Change-Over
Contact Resistance: <10m Ω
Service Life: <100,000 cycles
Max. Switching Capacity: 28VDC, 16A
EMC: Acc. To En 55014-1-2, EN 61000-3-2, EN 61000-3-3
Connection: 5 2.5mm2 5-pole terminal, clamping torque 0.5Nm max. rigid wire 2.5mm2 stranded wire (with wire end ferrule) 1.5mm2
Mounting: 35mm DIN clip for 35mm DIN rail, EN60715 or for exit filter EF 118 Series
Casing: UL94, Plastic according to UL94 V-0, light grey
Dimensions: 67 x 50 x 46mm
Weight: Approx. 80g
Fitting Position: Variable
Operating/Storage Temperature: 0 to + 60 °C (32 to + 140 °F) / -45 to +80 °C (-49 to + 176 °F)
Protection Type: IP20
| Art. No. | Operating Voltage | Setting Range |
| 01190.0-00 | 24VDC (20-28VDC) | 0 to +60°C |
