Switch Temperature Difference: 2K (± 1K Tolerance) at 25°C / 77°C (50% RH)
Switch Difference (Humidity): 4% RH (± 1% tolerance) at 25°C / 77°C (50% RH)
Reaction Time (Humidity): Approx. 5 sec.
Contact Type: Change-Over contact (relay)
Contact Resistance: <10m Ω
Service Life;
NC: >50,000 cycles
NO: >100,000 cycles
Max. Switching Capacity (Relay Output);
NC: 240VAC, 6 (1) A
NO: 240VAC, 8 (1.6) A
NC: 120VAC, 6 (1) A
NO: 120VAC, 8 (1.6) A
24VDC, 4A
EMC: Acc. to EN 55014-1-2, EN 61000-3-2, EN61000-3-3
Optical İndicator: LED
Connection: 5 2.5mm2 5-Pole terminal, clamping torque 0.5Nm max. rigid wire 2.5mm2 stranded wire (with wire end ferrule) 1.5mm2
Mounting: 35mm DIN Clip for 35mm DIN rail, EN6075 or for exit filter EF 118 Series
Casing: UL94, plastic according to UL94 V-0, light grey
Dimensions: 77 x 60 x 43mm
Weight: Approx. 0.20Kg
Fitting Position: Vertical
Operating/Storage Temperature: 0 to + 60 °C (+32 to + 140 °F) / -20 to +80 °C (-4 to + 176 °F)
Protection Type: IP20
Art. No. | Operating Voltage | Setting Range Temperature |
01230.0-00 | 230VAC, 50/60 Hz | 0 to + 60 °C |
01230.9-00 | 120VAC, 50/60 Hz | +32 to + 140 °F |
01230.9-01 | 120VAC, 50/60 Hz | 0 to + 60 °C |
