Siwitch temperature Differince : 7K (±4K tolerance )
Sensor element : Thermostatic bimetal
Contact Type : Snap - action contact
Contact resistance : < 10mΩ
Services life : > 100,000 cycles
Max. Switching capacity : 250VAC, 10(2) A - 120VAC 15(2) A - DC 30W
EMC : acc to EN 55014-1-2, EN 61000-3-2, EN 61000 -3-3
Connection : 2 2.5mm2 4-pole terminal,clamping torque 0.5Nm max.:rigid wire 2.5mm2 standed wire ( with wire end ferrule ) 1.5 mm2
Mounting : 35mm DIN clıp for 35 mm DIN rail,EN60715 or for exit filter EF 118 Series
Casing : Plastic according to UL 94 V-0,light grey
Dimensions : 67 x 50 x 46 mm
Weight : approx. 90 g
Fitting position : variable
Operatingg Storage Temperature : -20 to +80°C(-4 to + 176°F)
Protection type : IP20
