General Specifications
Motor Structure: Capacitor-run Induct external rotor motor
Motor Protection: Thermal Protect(Standard Speed) Impedance Protect
Impedance Protect (Half/Low Speed)
Insulation Resistance: 100 M Ω or over with a DC500 V Megger
Insulating Grade: B Protecting grade: IP54
Dielectric Withstand Voltage: AC 2500 V, at 0.5mA, 50/60 Hz
Allowable Ambient Temperature Range: -20 °C ~ +90 °C (Operating)
-40 °C ~ +80 °C (Storage)
Material
Casing: Die - cast aluminium
Impeller: Sheet steel
(direct welded Into motor and stove - enamelled in gray)
Bearing: Ball bearings
